DW-06-12-T-D-750-LL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
CONN HDR 12POS 0.1 STACK T/H TIN
PDF
/
Inventory: 7099
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Series Flex Stack, DW
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Connector Type BOARD STACKING CONNECTOR
Number of Positions 12
Color Black
Number of Rows 2
HTS Code 8536.69.40.40
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 12
Contact Gender MALE
Contact Finish - Post (Mating) Tin
Row Spacing 0.100 (2.54mm)
Packaging Bulk
Dimensions
Length - Stack Height 0.750 19.050mm
Length - Overall Pin 1.030 26.162mm
Length - Post (Mating) 0.170 4.318mm
Length - Tail 0.110 2.794mm
Compliance
RoHS Status ROHS3 Compliant
Physical
Mounting Type Through Hole
Supply Chain
Factory Lead Time 3 Weeks
