DW-04-11-T-S-285

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Rectangular Connector Board Spacer
PDF
/
Inventory: 4140
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Mounting Type Through Hole

Technical

Packaging Bulk
Published 2015
Series Flex Stack, DW
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Connector Type BOARD STACKING CONNECTOR
Number of Positions 4
Color Black
Number of Rows 1
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.100 2.54mm
Total Number of Contacts 4
Contact Gender MALE
Contact Finish - Post (Mating) Tin

Dimensions

Length - Stack Height 0.285 7.239mm
Length - Overall Pin 0.930 23.622mm
Length - Post (Mating) 0.535 13.589mm
Length - Tail 0.110 2.794mm

Compliance

RoHS Status ROHS3 Compliant
