DW-03-20-T-D-820-003
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Board Spacer
PDF
/
Inventory: 4961
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 3 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Insulation Material GLASS FILLED POLYESTER
Technical
Packaging Bulk
Series Flex Stack, DW
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
ECCN Code EAR99
Connector Type BOARD CONNECTOR
Number of Positions 6
Color Black
Number of Rows 2
Gender Male
Subcategory Headers and Edge Type Connectors
Pitch 0.100 2.54mm
Total Number of Contacts 6
Number of Conductors ONE
Reference Standard UL, CSA
Reliability COMMERCIAL
Body Length or Diameter 0.3 inch
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Operating Temperature (Min) -55°C
Contact Finish - Post (Mating) Tin
Contact Style SQ PIN-SKT
Row Spacing 0.100 (2.54mm)
Contact Pattern RECTANGULAR
Dimensions
Length - Stack Height 0.820 20.828mm
Length - Overall Pin 1.130 28.702mm
Length - Post (Mating) 0.200 5.080mm
Length - Termination 0.11 inch
Length - Tail 0.110 2.794mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
