DW-03-12-S-D-700-LL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Board Spacer
PDF
/
Inventory: 3812
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Length - Tail 0.110 2.794mm
Contact Finish Thickness - Post (Mating) 30.0μin 0.76μm
Length - Post (Mating) 0.220 5.588mm
Length - Overall Pin 1.030 26.162mm
Length - Stack Height 0.700 17.780mm
Technical
Row Spacing 0.100 (2.54mm)
Contact Finish - Post (Mating) Gold
UL Flammability Code 94V-0
Total Number of Contacts 6
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Male
Number of Rows 2
Color Black
Number of Positions 6
Connector Type BOARD STACKING CONNECTOR
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Series Flex Stack, DW
Published 2016
Packaging Bulk
Physical
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 3 Weeks
