DW-01-09-L-S-300

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Rectangular Connector Stacker
PDF
/
Inventory: 2858
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Mounting Type Through Hole

Technical

Packaging Bulk
Series Flex Stack, DW
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder
Number of Positions 1
Color Black
Number of Rows 1
Contact Finish - Post (Mating) Gold

Dimensions

Length - Stack Height 0.300 7.620mm
Length - Overall Pin 0.730 18.542mm
Length - Post (Mating) 0.320 8.128mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Tail 0.110 2.794mm

Compliance

RoHS Status ROHS3 Compliant
