DW-01-08-T-S-280

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description Conn Board Stacker HDR 1 POS Solder ST Thru-Hole
PDF
/
Inventory: 7265
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Technical

MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 1
Terminal Pitch 2.54mm
Contact Finish - Post (Mating) Tin
Gender Male
Number of Rows 1
Color Black
Number of Positions 1
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Flex Stack, DW
Packaging Bulk

Dimensions

Length - Stack Height 0.280 7.112mm
Length - Overall Pin 0.530 13.462mm
Length - Post (Mating) 0.140 3.556mm
Length - Tail 0.110 2.794mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant

Physical

Mounting Type Through Hole
Mount Through Hole
Contact Material PHOSPHOR BRONZE

Supply Chain

Factory Lead Time 3 Weeks
