M22-2680546
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 5+5 DIL EXT P/HDR 12MM BOARD STK HT
PDF
/
Inventory: 7919
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Tail 0.094 2.400mm
Length - Termination 0.094 inch
Length - Post (Mating) 0.138 3.500mm
Length - Overall Pin 0.705 17.900mm
Length - Stack Height 0.472 12.000mm
Technical
Contact Pattern RECTANGULAR
Durability 50 Cycles
Dielectric Withstanding Voltage 650VAC V
Body/Shell Style RECEPTACLE
Row Spacing 0.079 (2.00mm)
Contact Resistance 30mOhm
Contact Style SQ PIN-SKT
Contact Finish - Post (Mating) Tin
Rated Current (Signal) 1A
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender MALE
Body Breadth 0.157 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Body Length or Diameter 0.394 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 10
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature ROHS COMPLIANT
Number of Rows 2
Color Black
Number of Positions 10
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series M22
Packaging Bulk
Physical
Insulation Material NYLON
Mounting Type Through Hole
Contact Material PHOSPHOR BRONZE
