M22-2671505
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Headers & Wire Housings 15 PIN SIL EXTENDED VERT GOLD PIN HEADER
PDF
/
Inventory: 6459
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Length - Tail 0.094 2.400mm
Length - Termination 0.094 inch
Length - Post (Mating) 0.138 3.500mm
Length - Overall Pin 0.705 17.900mm
Length - Stack Height 0.472 12.000mm
Technical
Contact Pattern RECTANGULAR
Durability 300 Cycles
Dielectric Withstanding Voltage 650VAC V
Body/Shell Style PLUG
Contact Resistance 20mOhm
Contact Style SQ PIN-SKT
Contact Finish - Post (Mating) Gold
Rated Current (Signal) 1A
Body Depth 0.472 inch
UL Flammability Code 94V-0
Operating Temperature (Min) -40°C
Contact Gender MALE
Body Breadth 0.079 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 1
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Total Number of Contacts 15
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature ROHS COMPLIANT
Number of Rows 1
Color Black
Number of Positions 15
Connector Type BOARD STACKING CONNECTOR
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e4
Series M22
Published 2010
Packaging Bulk
Physical
Insulation Material NYLON
Mounting Type Through Hole
Contact Material NOT SPECIFIED
