926782-01-09-EU
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board Spacers, Stackers (Board to Board)
Description
Rectangular Connector Stacker
PDF
/
Inventory: 5708
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Length - Tail 0.545 13.843mm
Contact Finish Thickness - Post (Mating) 10.0μin 0.25μm
Length - Post (Mating) 0.100 2.540mm
Length - Overall Pin 1.245 31.623mm
Length - Stack Height 0.600 15.240mm
Length 31.623mm
Technical
Row Spacing 0.100 (2.54mm)
Contact Finish - Post (Mating) Gold
Pitch 0.100 2.54mm
Gender Male
Number of Rows 2
Color Black
Number of Positions 18
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 929
Published 2004
Packaging Bulk
Physical
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 3 Weeks
