90584-1326
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board In, Direct Wire to Board
Description
CONN RECEPT IDT 26POS 1.27MM TIN
PDF
/
Buying Options
Total Price: USD $1.44
Unit Price: USD $1.439652
≥1 USD $1.439652
≥10 USD $1.358155
≥100 USD $1.281285
≥500 USD $1.208759
≥1000 USD $1.140337
Inventory: 6770
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC Unknown
Technical
Voltage - Working 250V
Glow Wire Compliant Non-compliant
Contact Rating (Current) 1.2A
Contact Pattern STAGGERED
Wire/Cable Gauge 26 AWG
Durability 30 Cycles
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Dielectric Withstanding Voltage 750VAC V
Insulation Resistance 1000000000Ohm
Contact Resistance 15mOhm
Contact Style IDC
Housing Color White
UL Flammability Code 94V-0
PCB Contact Pattern STAGGERED
Lead Pitch 1.27mm
Number Of PCB Rows 2
Row Spacing - Mating 2.54 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 1.2A
Orientation Straight
Total Number of Contacts 26
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature LOW PROFILE
Voltage - Rated 250V
Gender Receptacle
Number of Rows 2
Color Natural, White
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 26
Connector Type Cable, IDC
ECCN Code EAR99
Termination Through Hole
Pbfree Code yes
JESD-609 Code e3
Physical
Housing Material Polyester
Mount Press Fit, Through Hole
Contact Plating Tin
Contact Material Bronze
