0905842312
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board In, Direct Wire to Board
Description
Conn IDC Connector RCP 12 POS 1.27mm Solder RA Thru-Hole Picoflex? Tube
PDF
/
Inventory: 7717
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 80.0μin 2.03μm
Technical
Board-Side Pitch 0.100 2.54mm
Cable Pitch 0.050 1.27mm
Cable Termination IDC
Termination Type SOLDER
Body/Shell Style RECEPTACLE
Row Spacing 0.100 (2.54mm)
Wire Gauge 26-28 AWG, Stranded
Contact Gender FEMALE
Contact Finish Tin
Number of Positions Loaded All
Total Number of Contacts 12
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature LOW PROFILE
Number of Rows 2
Color White
Number of Positions 12
Connector Type Ribbon Cable, DIP Header
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed End
JESD-609 Code e3
Series Picoflex 90584
Packaging Tube
Physical
Mounting Type Through Hole, Press-Fit
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 30 Weeks
