0905842310

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board In, Direct Wire to Board
Description Picoflex 90584 ROHS3Compliant GENERAL PURPOSE Closed End Connector Ribbon Cable, DIP Header 0.100 2.54mm
PDF
/
Inventory: 7025
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Contact Finish Thickness 80.0μin 2.03μm

Technical

Board-Side Pitch 0.100 2.54mm
Cable Pitch 0.050 1.27mm
Cable Termination IDC
Termination Type SOLDER
Body/Shell Style RECEPTACLE
Row Spacing 0.100 (2.54mm)
Wire Gauge 26-28 AWG, Stranded
Contact Gender FEMALE
Contact Finish Tin
Number of Positions Loaded All
Total Number of Contacts 10
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Additional Feature LOW PROFILE
Number of Rows 2
Color White
Number of Positions 10
Connector Type Ribbon Cable, DIP Header
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Closed End
JESD-609 Code e3
Series Picoflex 90584
Packaging Tube

Physical

Mounting Type Through Hole, Press-Fit
Contact Material PHOSPHOR BRONZE

Supply Chain

Factory Lead Time 30 Weeks
