0520040810

Molex
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board In, Direct Wire to Board
Description Conn Ribbon Cable Connector F 8 POS 1.5mm Solder ST Thru-Hole Tray
PDF
/
Inventory: 3845
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Technical

Board-Side Pitch 0.118 3.00mm
Cable Pitch 0.059 1.50mm
Cable Termination Poke-In
Wire Gauge (Min) 24 AWG
Wire Gauge (Max) 26 AWG
Max Voltage Rating (AC) 150V
Number of Circuits 7
Wire Gauge 24-26 AWG
Contact Finish Tin
Current Rating 2.5A
Number of Positions Loaded All
Orientation Straight
Total Number of Contacts 8
Pitch 1.5mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 8
Connector Type Ribbon Cable
Termination Wire Wrap
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Cover
Series 52004
Packaging Tray

Physical

Mounting Type Through Hole, Press-Fit
Mount Press Fit, Through Hole
Contact Material NOT SPECIFIED
