09181509422
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Board In, Direct Wire to Board
Description
Headers & Wire Housings SEK PBC SVML 2R 50P SN-DESIGN 2 LP K
PDF
/
Buying Options
Total Price: USD $1.58
Unit Price: USD $1.5752
≥1 USD $1.5752
≥10 USD $1.43264
≥100 USD $1.356608
≥500 USD $1.32528
≥1000 USD $1.262096
≥3000 USD $1.111
Inventory: 245
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Physical
Contact Material Nickel
Mount Through Hole
Mounting Type Through Hole, Kinked Pin
Housing Material Thermoplastic
Technical
Packaging Bulk
Series SEK
JESD-609 Code e3
Feature Feed Through
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
ECCN Code EAR99
Connector Type Ribbon Cable, DIP Header
Number of Positions 50
Number of Rows 2
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating SN ON NI
Pitch 2.54mm
Total Number of Contacts 50
Number of Positions Loaded All
Current Rating 2A
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 2
PCB Contact Pattern RECTANGULAR
Operating Temperature (Max) 105°C
Contact Gender FEMALE
Operating Temperature (Min) -55°C
Body Depth 0.177 inch
Rated Current (Signal) 2A
Contact Style IDC
Contact Resistance 10mOhm
Row Spacing 0.100 (2.54mm)
Polarization Key POLARIZED HOUSING
Contact Pattern RECTANGULAR
Cable Termination IDC
Insulator Color GRAY
Board-Side Pitch 0.100 2.54mm
Dimensions
Height 5.5mm
Length - Termination 0.13 inch
Compliance
RoHS Status ROHS3 Compliant
