99436-0016T
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board In, Direct Wire to Board
Description
CONN DIP HDR IDC 36P 28AWG VERT
PDF
/
Inventory: 7272
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Plating Tin
Mount Through Hole
Mounting Type Through Hole
Housing Material Thermoplastic
Technical
Packaging Bulk
Published 2004
Series 994
Feature Feed Through
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
Connector Type Ribbon Cable, DIP Header
Number of Positions 36
Max Operating Temperature 105°C
Min Operating Temperature -55°C
Color Black
Number of Rows 2
Pitch 2.54mm
Orientation Right Angle
Depth 6mm
Number of Positions Loaded All
Current Rating 1A
Contact Finish Tin-Lead
Lead Pitch 2.54mm
Number of Contacts 36
Housing Color Black
Wire Gauge 28 AWG, Stranded
Row Spacing 0.100 (2.54mm)
Max Current Rating 1A
Wire/Cable Gauge 28 AWG
Cable Termination IDC
Cable Pitch 0.050 1.27mm
Board-Side Pitch 0.100 2.54mm
Dimensions
Length 50.52mm
Width 6mm
Contact Finish Thickness 100.0μin 2.54μm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
