7830-0006PR
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Board In, Direct Wire to Board
Description
CONN 30POS .1X.1 IDC RIBBON PCB
PDF
/
Inventory: 1711
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Contact Finish Thickness Flash
Technical
Board-Side Pitch 0.100 2.54mm
Cable Pitch 0.050 1.27mm
Cable Termination IDC
Wire Gauge (Min) 26 AWG
Wire Gauge (Max) 28 AWG
Row Spacing 0.100 (2.54mm)
Wire Gauge 26 AWG, Stranded; 28 AWG, Solid or Stranded; 30 AWG, Solid
Housing Color Grey
Number of Contacts 30
Contact Finish Gold
Current Rating 1A
Number of Positions Loaded All
Pitch 2.54mm
Gender Male
Number of Rows 2
Color Gray
Number of Positions 30
Connector Type Ribbon Cable, DIP Header
Termination IDT
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Feature Feed Through
Series 78XX
Published 2006
Packaging Tray
Physical
Housing Material Plastic
Mounting Type Through Hole
Mount Through Hole
Contact Plating Gold
Contact Material Copper
