87433-0530
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Arrays, Edge Type, Mezzanine (Board to Board)
Description
CONN RECEPT 9POS 1MM VERT SMD
PDF
/
Inventory: 5677
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Surface Mount
Housing Material Plastic
Technical
Published 2001
Part Status Discontinued
Connector Type Receptacle
Number of Positions 9
Number of Rows 2
Additional Feature STAGGERED CONFIGURATION, POLARIZATION AVAILABLE
Subcategory Headers and Edge Type Connectors
Contact Finish - Mating AU
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 990.6μm
Total Number of Contacts 9
Orientation Vertical
Reach Compliance Code unknown
Number of Conductors ONE
Reference Standard UL
Reliability COMMERCIAL
Number Of PCB Rows 2
Lead Pitch 1mm
PCB Contact Pattern STAGGERED
Operating Temperature (Max) 85°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender FEMALE
Operating Temperature (Min) -30°C
Housing Color Beige
Body Depth 0.13 inch
Rated Current (Signal) 1A
Contact Style BELLOWED TYPE
Contact Resistance 30mOhm
Insulation Resistance 1000000000Ohm
Polarization Key D-SHAPE
Dielectric Withstanding Voltage 500VDC V
Contact Pattern STAGGERED
Glow Wire Compliant Non-compliant
Dimensions
Height 3.3mm
Length 9.3mm
Width 5mm
Plating Thickness 30μin
Stack Height (Mating) 7mm
Compliance
RoHS Status Non-RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
