87605-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description
Headers & Wire Housings 20 MODII HDR DRST SHRD 0.100CL
PDF
/
Buying Options
Total Price: USD $26.24
Unit Price: USD $26.24167
≥1 USD $26.24167
≥10 USD $24.756299
≥100 USD $23.354992
≥500 USD $22.033009
≥1000 USD $20.785867
Inventory: 2435
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Technical
High Speed Serial Data Connector No
Shrouded End Dimension 3.81 mm
Convert To (Adapter End) Plug, Male Pins
Convert From (Adapter End) Plug, Male Pins
Mating Post Length 8.08mm
Contact Current Rating 3A
ELV Compliant
Row Spacing 0.100 (2.54mm)
Insulation Resistance 5GOhm
Lead Length 8.38mm
Housing Color Black
UL Flammability Code 94V-0
Contact Gender Male
Approval Agency CSA
Current Rating 3A
Orientation Vertical
Total Number of Contacts 20
Pitch 0.100 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Min Operating Temperature -65°C
Max Operating Temperature 105°C
Number of Positions 20
Connector Type Header, Pin, Plug
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series AMPMODU Mod II
Published 2008
Physical
Housing Material Nylon
Contact Shape Square
Mounting Type Panel Mount, Flange
Mount Bulkhead
Contact Plating Gold
Contact Material Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 14 Weeks
