7-292254-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description
Headers & Wire Housings CT RELAY HDR ASSY 10P BLACK
PDF
/
Inventory: 6124
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Plating Thickness 40μin
Width 5.9944mm
Length 23.78mm
Height 11.9888mm
Technical
Wire Size (Min) 30 AWG
Convert To (Adapter End) Plug, Male Pins
Convert From (Adapter End) Plug, Male Pins
Contact Design PREASSEM CONN
Mating Post Length 4.4958mm
Contact Current Rating 4A
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
Termination Type CRIMP
ELV Compliant
Contact Style RND PIN-SKT
Rated Current (Signal) 4A
Operating Supply Voltage 125V
Body Depth 0.472 inch
Housing Color Black
UL Flammability Code 94V-0
Body Breadth 0.268 inch
Approval Agency CSA
Reliability COMMERCIAL
Total Number of Contacts 10
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.69.40.40
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 10
Connector Type Header, Pin, Plug
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series CT
Published 2010
Physical
Shape Rectangular
Housing Material Nylon
Contact Shape Round
Mounting Type Panel Mount, Snap-In
Mount Panel
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 18 Weeks
