6-292215-2
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description
Headers & Wire Housings MINI CT SGL RELAY 12P BLUE
PDF
/
Inventory: 2402
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Panel Thickness 1.6mm
Width 6.7mm
Length 26.1mm
Height 11.8mm
Technical
Convert To (Adapter End) Plug, Male Pins
Convert From (Adapter End) Plug, Male Pins
Mating Post Length 2.4mm
Insulation Diameter 1.0414 mm
Contact Current Rating 2A
Contact Finish Termination TIN
Wire/Cable Gauge 24 AWG
Wire/Cable Type Discrete
Max Voltage Rating (AC) 50V
ELV Compliant
Contact Resistance 30mOhm
Operating Supply Voltage 50V
UL Flammability Code 94V-0
Approval Agency CSA
Depth 6.5mm
Orientation Straight
Total Number of Contacts 12
Pitch 0.059 1.50mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating TIN
Number of Rows 1
Color Blue
Min Operating Temperature -30°C
Max Operating Temperature 105°C
Number of Positions 12
Connector Type Header, Pin, Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series Mini CT
Published 2004
Physical
Shape Rectangular
Housing Material Nylon
Contact Shape Square
Mounting Type Panel Mount, Snap-In
Mount Panel
Contact Plating Tin
Contact Material Brass
Supply Chain
Factory Lead Time 15 Weeks
