5-292215-7 image
Favorite
5-292215-7 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description Headers & Wire Housings MINI CT SGL RELAY 7P BLUE
PDF
/
Inventory: 920
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 11 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 week ago)

Physical

Contact Material Brass
Contact Plating Tin
Mount Panel
Mounting Type Panel Mount, Snap-In
Contact Shape Square
Housing Material Nylon
Shape Rectangular

Technical

Published 2004
Series Mini CT
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Connector Type Header, Pin, Plug
Number of Positions 7
Max Operating Temperature 105°C
Min Operating Temperature -30°C
Color Blue
Number of Rows 1
HTS Code 8536.69.40.40
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.059 1.50mm
Total Number of Contacts 7
Approval Agency CSA
UL Flammability Code 94V-0
Operating Supply Voltage 50V
ELV Compliant
Wire/Cable Type Discrete
Wire/Cable Gauge 24 AWG
Contact Finish Termination TIN
Contact Current Rating 2A
Insulation Diameter 1.0414 mm
Mating Post Length 2.4mm
Convert From (Adapter End) Plug, Male Pins
Convert To (Adapter End) Plug, Male Pins

Dimensions

Height 11.8mm
Length 18.5928mm
Width 6.7mm
Panel Thickness 1.6mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
