4-292254-7
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description
CONN ADAPT PLUG/PLUG 7POS 2MM
PDF
/
Inventory: 4153
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Width 5.9944mm
Plating Thickness 40μin
Length 17.78mm
Height 11.9888mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
Technical
Wire Size (Min) 30 AWG
Convert To (Adapter End) Plug, Male Pins
Convert From (Adapter End) Plug, Male Pins
Contact Design PREASSEM CONN
Mating Post Length 4.4958mm
Contact Current Rating 4A
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
Polarization Key POLARIZED HOUSING
Termination Type CRIMP
ELV Compliant
Contact Style RND PIN-SKT
Rated Current (Signal) 4A
Operating Supply Voltage 125V
Housing Color Yellow
Body Breadth 0.268 inch
Approval Agency UL
Reliability COMMERCIAL
Total Number of Contacts 7
Pitch 0.079 2.00mm
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 7
Connector Type Header, Pin, Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CT
Published 2009
Physical
Shape Rectangular
Housing Material Nylon
Contact Shape Round
Mounting Type Panel Mount, Snap-In
Mount Panel
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 14 Weeks
