4-292156-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description
Headers & Wire Housings CT RELAY HDR ASSY FREE HANGING
PDF
/
Inventory: 6134
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 5.9944mm
Length 11.7983mm
Height 11.9888mm
Technical
Convert To (Adapter End) Plug, Male Pins
Convert From (Adapter End) Plug, Male Pins
Mating Post Length 4.4958mm
Contact Current Rating 4A
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
Termination Type SOLDER
ELV Compliant
Operating Supply Voltage 125V
Housing Color Yellow
Approval Agency UL
Orientation Vertical
Total Number of Contacts 4
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 4
Connector Type Header, Pin, Plug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series CT
Published 2009
Physical
Shape Rectangular
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 8 Weeks
