4-292156-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description
Headers & Wire Housings CT RELAY HDR ASSY FREE HANGING
PDF
/
Inventory: 9318
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Physical
Contact Material Brass
Contact Plating Tin
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Housing Material Nylon
Shape Rectangular
Technical
Published 2007
Series CT
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type Header, Pin, Plug
Number of Positions 3
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Number of Rows 1
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.079 2.00mm
Total Number of Contacts 3
Orientation Vertical
Approval Agency UL
UL Flammability Code 94V-0
Housing Color Yellow
Operating Supply Voltage 125V
ELV Compliant
Termination Type SOLDER
Wire/Cable Type Discrete
Wire/Cable Gauge 22 AWG
Contact Current Rating 4A
Mating Post Length 4.4958mm
Convert From (Adapter End) Plug, Male Pins
Convert To (Adapter End) Plug, Male Pins
Dimensions
Height 11.9888mm
Length 9.8mm
Width 5.9944mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
