292254-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description
CONN HEADER 6POS 2MM TIN PANEL
PDF
/
Buying Options
Total Price: USD $0.87
Unit Price: USD $0.8712
≥1 USD $0.8712
≥10 USD $0.82984
≥100 USD $0.683936
≥500 USD $0.621755
≥1000 USD $0.537636
≥3000 USD $0.46083
Inventory: 2657
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 5.9944mm
Length 15.7734mm
Height 11.9888mm
Technical
Convert To (Adapter End) Plug, Male Pins
Convert From (Adapter End) Plug, Male Pins
Mating Post Length 4.4958mm
Contact Current Rating 4A
Max Voltage Rating (DC) 125.125kV
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
Max Voltage Rating (AC) 125V
ELV Compliant
Contact Resistance 20mOhm
Operating Supply Voltage 125V
Housing Color Natural
Contact Gender Male
Number of Contacts 6
Approval Agency UL
Current Rating 4A
Depth 12mm
Orientation Straight
Pitch 0.079 2.00mm
Voltage - Rated 125V
Gender Male to Male
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 6
Connector Type Header, Pin, Plug
Termination Through Hole
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series CT
Published 2005
Physical
Shape Rectangular
Housing Material Nylon
Contact Shape Round
Mounting Type Panel Mount, Snap-In
Mount Panel
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 13 Weeks
