292254-5
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description
CONN HEADER 5POS 2MM TIN PANEL
PDF
/
Buying Options
Total Price: USD $0.57
Unit Price: USD $0.572
≥1 USD $0.572
≥10 USD $0.54912
≥100 USD $0.452232
≥500 USD $0.425797
Inventory: 10629
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Material Brass
Contact Plating Tin
Mount Panel
Mounting Type Panel Mount, Snap-In
Contact Shape Round
Housing Material Nylon
Shape Rectangular
Technical
Packaging Bulk
Published 2005
Series CT
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
Connector Type Header, Pin, Plug
Number of Positions 5
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Number of Rows 1
Gender Male to Male
Voltage - Rated 125V
Pitch 0.079 2.00mm
Orientation Straight
Depth 12mm
Current Rating 4A
Approval Agency UL
Number of Contacts 5
Contact Gender Male
Housing Color Natural
Operating Supply Voltage 125V
Contact Resistance 20mOhm
ELV Compliant
Max Voltage Rating (AC) 125V
Wire/Cable Type Discrete
Wire/Cable Gauge 22 AWG
Max Voltage Rating (DC) 125V
Contact Current Rating 4A
Mating Post Length 4.4958mm
Convert From (Adapter End) Plug, Male Pins
Convert To (Adapter End) Plug, Male Pins
Dimensions
Height 11.9888mm
Length 13.7668mm
Width 5.9944mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
