292156-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description
CONN HEADER CT 6POS FREE HANGING
PDF
/
Buying Options
Total Price: USD $0.84
Unit Price: USD $0.836
≥1 USD $0.836
≥10 USD $0.79992
≥100 USD $0.764896
≥500 USD $0.754336
≥1000 USD $0.65912
≥3000 USD $0.634418
Inventory: 6078
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Width 5.9944mm
Length 15.8mm
Height 11.9888mm
Technical
Convert To (Adapter End) Plug, Male Pins
Convert From (Adapter End) Plug, Male Pins
Mating Post Length 4.4958mm
Contact Current Rating 4A
Wire/Cable Gauge 22 AWG
Wire/Cable Type Discrete
Max Voltage Rating (AC) 125V
ELV Compliant
Contact Resistance 20mOhm
Operating Supply Voltage 125V
Housing Color Natural, White
UL Flammability Code 94V-0
Contact Gender Male
Approval Agency UL
Current Rating 4A
Depth 12mm
Orientation Vertical
Total Number of Contacts 6
Pitch 0.079 2.00mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 125V
Number of Rows 1
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Number of Positions 6
Connector Type Header, Pin, Plug
ECCN Code EAR99
Termination Crimp
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series CT
Published 2010
Packaging Bulk
Physical
Shape Rectangular
Housing Material Nylon
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Plating Tin
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 13 Weeks
