1473571-6
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description
Power to the Board RITS JUNCTION BOX 2D 6P P/M
PDF
/
Buying Options
Total Price: USD $3.54
Unit Price: USD $3.5376
≥1 USD $3.5376
≥10 USD $3.14952
≥100 USD $2.796112
≥500 USD $2.297979
Inventory: 862
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 18 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Contact Plating Gold
Mount Panel
Mounting Type Panel Mount, Snap-In
Housing Material Thermoplastic
PCB Mount Retention Without
Technical
Published 2002
Series RITS
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Connector, Receptacle, Socket
Number of Positions 6
Max Operating Temperature 167°C
Min Operating Temperature -22°C
Number of Rows 1
Gender Female
Pitch 0.079 2.00mm
Orientation Straight
Shielding Unshielded
Current Rating 3A
Number of Contacts 6
Housing Color Black
ELV Compliant
Max Voltage Rating (DC) 32V
Sealable No
Contact Current Rating 3A
Halogen Free Halogen Free
Mating Retention With
Contact Retention Without
Convert From (Adapter End) Receptacle, Female Sockets
Convert To (Adapter End) Receptacle, Female Sockets
Mating Alignment With
Preloaded Yes
Dimensions
Height 30mm
Length 19.8mm
Width 15.9258mm
Panel Thickness 2mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
