1-292215-3 image
Favorite
1-292215-3 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Adapters
Description CONN ADAPT PLUG/PLUG 13POS 1.5MM
PDF
/
Buying Options
Total Price: USD $0.62
Unit Price: USD $0.616
≥1 USD $0.616
≥10 USD $0.58432
≥100 USD $0.481536
≥500 USD $0.453323
Inventory: 5163
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 25 Weeks
Lifecycle Status ACTIVE (Last Updated: 1 day ago)

Physical

Contact Material Brass
Contact Plating Tin
Mount Panel
Mounting Type Panel Mount, Snap-In
Contact Shape Square
Housing Material Nylon
Shape Rectangular

Technical

Packaging Bulk
Published 2004
Series Mini CT
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Through Hole
Connector Type Header, Pin, Plug
Number of Positions 13
Max Operating Temperature 105°C
Min Operating Temperature -30°C
Color White
Number of Rows 1
Voltage - Rated 50V
Contact Finish - Mating TIN
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 0.059 1.50mm
Total Number of Contacts 13
Orientation Straight
Current Rating 2A
Approval Agency CSA
Contact Gender Male
UL Flammability Code 94V-0
Housing Color Natural, White
Operating Supply Voltage 50V
Contact Resistance 30mOhm
ELV Compliant
Wire/Cable Type Discrete
Wire/Cable Gauge 24 AWG
Max Voltage Rating (DC) 5.05kV
Contact Current Rating 2A
Insulation Diameter 1.0414 mm
Mating Post Length 2.4mm
Convert From (Adapter End) Plug, Male Pins
Convert To (Adapter End) Plug, Male Pins

Dimensions

Height 11.8mm
Length 27.5844mm
Width 6.7mm
Panel Thickness 1.6mm

Compliance

Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Not Applicable
