794282-1 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Rectangular Connectors - Accessories
Description Universal MATE-N-LOK RoHS Compliant IP57 1998 (Connector Style) Connector 16AWG 120C 19A 600V
PDF
/
Buying Options
Total Price: USD $2.65
Unit Price: USD $2.6488
≥1 USD $2.6488
≥10 USD $2.36104
≥100 USD $2.083796
≥500 USD $1.722442
≥1000 USD $1.49358
Inventory: 2695
Minimum: 1
-
+

Technical Details

Compliance

Ratings IP57
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No

Dimensions

Length 33.02mm
Height 10.16mm

Technical

Wire/Cable Diameter 3.3 mm
Insulation Diameter 3.302 mm
Accessory Type Plug, Sealing
Wire Gauge (Min) 30 AWG
Wire Gauge (Max) 16 AWG
Wire/Cable Type Discrete
Empty Shell NO
Contact Gender Female
Number of Contacts 15
Current Rating 19A
Depth 20.32mm
Pitch 6.35mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 600V
Number of Rows 3
Color Blue
Min Operating Temperature -55°C
Max Operating Temperature 120°C
Connector Type COMBINATION LINE CONNECTOR
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Splash-Proof
Series Universal MATE-N-LOK
Published 1998
Packaging Bulk

Physical

Housing Material Rubber
Material Rubber, Silicone
Mounting Type CABLE

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 4 Weeks
