2103247-6
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Accessories
Description
SPLIT HEADER ASSY, KEY F, HVA280
PDF
/
Buying Options
Total Price: USD $10.48
Unit Price: USD $10.4808
≥1 USD $10.4808
≥10 USD $8.875293
≥100 USD $8.223477
≥500 USD $7.872454
≥1000 USD $7.020015
Inventory: 75
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width - Tab 2.8mm
Tab Thickness 800μm
Width 40.6mm
Length 45.212mm
Technical
Contact Arrangement S0P2
Circuit Application Signal
Max Voltage Rating (DC) 750V
Body/Shell Style RECEPTACLE
Contact Style BLADE PIN-SKT
Body Depth 1.224 inch
Contact Gender FEMALE
Body Breadth 1.598 inch
Reliability COMMERCIAL
Number of Conductors ONE
Shielding Shielded
Total Number of Contacts 2
Mixed Contacts YES
Subcategory Headers and Edge Type Connectors
Color Orange
Min Operating Temperature -40°C
Max Operating Temperature 140°C
Connector Type BOARD CONNECTOR
Part Status Active
Published 2013
Physical
Mounting Style STRAIGHT
Mounting Option 1 LOCKING
Contact Plating Silver
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 9 Weeks
