TCSD-04-S-04.17-01
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cable Assemblies / Rectangular Cable Assemblies
Description
2MM DOUBLE ROW FEMALE IDC ASSEMB
PDF
/
Inventory: 10046
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Length 0.348' 105.92mm 4.17
Technical
Pitch - Cable 0.039 1.00mm
Pitch - Connector 0.079 2.00mm
Cable Termination IDC
Termination Type IDC
Contact Gender FEMALE
Contact Finish Gold
Shielding Unshielded
Total Number of Contacts 8
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Number of Rows 2
Color Gray, Ribbon
Number of Positions 8
Connector Type Socket to Cable
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Series Tiger Eye? TCSD
Physical
Contact Material BERYLLIUM COPPER
Supply Chain
Factory Lead Time 3 Weeks
