SFSD-25-30-H-32.00-S

Samtec Inc.
RoHS
RoHS RoHS compliant
Package /
Category Cable Assemblies / Rectangular Cable Assemblies
Description Cable Assembly Discrete Wire 0.812m 30AWG 50 POS Discrete Wire Housing SKT Crimp Bulk
PDF
/
Inventory: 2771
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 3 Weeks

Physical

Contact Material BERYLLIUM COPPER
Mounting Style STRAIGHT

Technical

Packaging Bulk
Series Tiger Eye? SFSD
JESD-609 Code e4
Feature Polarizing Key
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Connector Type Socket to Individual Wire Leads
Number of Positions 50
Color Black, Individual
Number of Rows 2
Gender Female
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 50
Shielding Unshielded
Contact Finish Gold
Reliability COMMERCIAL
Operating Temperature (Max) 80°C
Operating Temperature (Min) -10°C
Body Depth 0.44 inch
Contact Style SQ PIN-SKT
Mating Contact Pitch 0.05 inch
Wire/Cable Type Discrete
Cable Length 812mm
Contact Pattern RECTANGULAR
Cable Termination Crimp
Mating Contact Row Spacing 0.05 inch
Pitch - Connector 0.050 1.27mm

Dimensions

Length 2.67' 812.80mm
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
