NTP1-24SL1
RoHS
/
Package /
Category Cable Assemblies / Rectangular Cable Assemblies
Description
MICRO
PDF
/
Buying Options
Total Price: USD $861.14
Unit Price: USD $861.142926
≥1 USD $861.142926
Inventory: 7847
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 38 Weeks
Physical
Contact Material NICKEL- SILVER
Insulation Material PHENOLIC
Shell Material PHENOLIC
Technical
Published 2011
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
ECCN Code EAR99
Connector Type COMBINATION LINE CONNECTOR
Number of Rows 1
Additional Feature WIRE, UNINSULATED
HTS Code 8536.69.40.30
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Total Number of Contacts 24
Reach Compliance Code compliant
Reliability COMMERCIAL
Body Length or Diameter 0.625 inch
Operating Temperature (Max) 125°C
Body Breadth 0.055 inch
Contact Gender FEMALE
Operating Temperature (Min) -55°C
Empty Shell NO
Body Depth 0.22 inch
Rated Current (Signal) 1A
Contact Style RND PIN-SKT
Contact Resistance 80mOhm
Insulation Resistance 5000000000Ohm
Mating Contact Pitch 0.025 inch
Body/Shell Style RECEPTACLE
Termination Type WIRE
Dielectric Withstanding Voltage 350VAC V
Durability 500 Cycles
Contact Pattern RECTANGULAR
Insertion Force-Max 1.668 N
Wire Size (Min) 32 AWG
Wire Size (Max) 32 AWG
Dimensions
Length - Termination 0.75 inch
