MJSV-28PL61
RoHS
/
Package /
Category Cable Assemblies / Rectangular Cable Assemblies
Description
Cable Assembly Uninsulated Wire 0.003m 25AWG 28 POS Rectangular PIN
PDF
/
Inventory: 6812
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length - Termination 0.125 inch
Plating Thickness 50μin
Technical
Insulator Color BLACK
Mating Contact Row Spacing 0.065 inch
Withdrawl Force-Min .139 N
Insertion Force-Max 2.224 N
Contact Pattern STAGGERED
Contact Finish Termination Gold (Au)
Durability 500 Cycles
Cable Length 3mm
Dielectric Withstanding Voltage 900VAC V
Termination Type WIRE
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.08 inch
Insulation Resistance 5000000000Ohm
Contact Resistance 10mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.432 inch
Operating Temperature (Min) -55°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 125°C
Body Length or Diameter 1.02 inch
Reliability COMMERCIAL
Total Number of Contacts 28
Option WITH CABLE ASSEMBLY
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating GOLD (50)
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature LOW PROFILE, POLARIZED, SHROUDED
Gender Male
Number of Rows 3
Connector Type Rectangular
ECCN Code EAR99
Part Status Active
Pbfree Code no
JESD-609 Code e4
Packaging Bulk
Physical
Mounting Option 2 JACKSCREW
Mounting Option 1 #1-64
Insulation Material GLASS FILLED POLYESTER
Number of Pins 28
Mounting Type CABLE
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 18 Weeks
