MJSR-42PH003
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cable Assemblies / Rectangular Cable Assemblies
Description
Cable Assembly Insulated Wire 0.457m 26AWG 42 POS Rectangular PIN
PDF
/
Buying Options
Total Price: USD $185.32
Unit Price: USD $185.3192
≥1 USD $185.3192
≥10 USD $171.3448
≥100 USD $164.7536
Inventory: 72
Minimum: 1
-
+
Technical Details
Physical
Contact Material COPPER ALLOY
Mounting Type CABLE
Number of Pins 42
Insulation Material POLYPHENYLENE SULPHIDE
Mounting Option 1 #1-64
Technical
Packaging Bulk
Pbfree Code no
Part Status Active
ECCN Code EAR99
Connector Type Rectangular
Number of Rows 4
Additional Feature SHROUDED
HTS Code 8536.69.40.40
Subcategory D Type Connectors
Contact Finish - Mating GOLD (50)
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option WITH CABLE ASSEMBLY
Total Number of Contacts 42
Reliability COMMERCIAL
Body Length or Diameter 1.445 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender MALE
Body Depth 0.357 inch
Contact Style RND PIN-SKT
Mating Contact Pitch 0.1 inch
Body/Shell Style RECEPTACLE
Wire/Cable Type Insulated Wire
Cable Length 457mm
Contact Pattern STAGGERED
Mating Contact Row Spacing 0.075 inch
Insulator Color BLACK
Contact Design PREASSEM CONN
Wire Size (Min) 26 AWG
Wire Size (Max) 25 AWG
Dimensions
Plating Thickness 50μin
Length - Termination 0.09 inch
Compliance
RoHS Status RoHS Compliant
