22-036-116
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cable Assemblies / Rectangular Cable Assemblies
Description
Jumper Wires DIP-ER LOGIC JUMPERS 22 CONDUCTORS
PDF
/
Inventory: 8685
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Pitch - Connector 0.100 2.54mm
Pitch - Cable 0.035 0.89mm
Connector Type A Header Stripped Pin
Connector Type B Header Stripped Pin
Cable Termination Solder
Wire/Cable Gauge 28 AWG
Number of Contacts 22
Contact Finish Gold
Current Rating 1A
Shielding Unshielded
Voltage - Rated 300V
Gender Male to Male
Number of Rows 2
Color Multiple, Ribbon
Connector Type DIP to DIP, Reversed
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series 116
Published 2006
Dimensions
Length 3.00' 914.40mm
Contact Finish Thickness 10.0μin 0.25μm
Compliance
RoHS Status ROHS3 Compliant
Physical
Insulation Material PVC
Supply Chain
Factory Lead Time 9 Weeks
