20-036-215
RoHS
RoHS compliant
RoHS compliantPackage /
Category Cable Assemblies / Rectangular Cable Assemblies
Description
Multiple Ribbon DIP to DIP Reversed 215 Socket (0.1) Board In Rectangular Cable Assembly 3.00' 914.40mm 28AWG 300V 1A
PDF
/
Inventory: 2843
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Insulation Material PVC
Technical
Published 2006
Series 215
Feature Strain Relief
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Connector Type DIP to DIP, Reversed
Color Multiple, Ribbon
Number of Rows 2
Gender Male to Female
Voltage - Rated 300V
Shielding Unshielded
Current Rating 1A
Contact Finish Gold
Number of Contacts 20
Wire/Cable Gauge 28 AWG
Cable Termination Solder
Usage Socket (0.1), Board In
Pitch - Connector 0.100 2.54mm
Pitch - Cable 0.050 1.27mm
Connector Type A Header Stripped Pin
Connector Type B Socket
Dimensions
Length 3.00' 914.40mm
Contact Finish Thickness 10.0μin 0.25μm
Compliance
RoHS Status ROHS3 Compliant
