TPBF11CGRA0
RoHS
/
Package /
Category Switches / Pushbutton Switches
Description
Pushbutton Switches SPST-NO Momentary RA
PDF
/
Inventory: 1595
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 19 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold
Mount Through Hole
Mounting Type Through Hole, Right Angle
Housing Material Polyester
Actuator Material Polyamide
Technical
Operating Temperature -30°C~65°C
Packaging Bulk
Published 2010
Series TP
JESD-609 Code e0
Pbfree Code no
Part Status Active
Termination PC Pins
ECCN Code EAR99
Type Standard
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8536.50.90.31
Power Rating 400mW
Voltage - Rated DC 20V
Current Rating (Amps) 0.4VA AC/DC
Orientation Right Angle
Reach Compliance Code not_compliant
Current Rating 400mA
Termination Style PC Pin
Voltage - Rated AC 20V
Body Breadth 5.3 mm
Actuator Type Round, Plunger, Flush
Circuit SPST-NO
Switch Function Off-Mom
Contact Resistance 20mOhm
Color - Actuator/Cap Black
Contact Current(DC)-Max 0.02A
Sealing EPOXY TERMINAL SEALED
Max Voltage Rating (AC) 20V
Electrical Life 100,000 Cycles
Throw Configuration SPST
Max Voltage Rating (DC) 20V
Contact Current(AC)-Max 0.02A
Contact (AC) Max Rating R Load .02A@20VAC
Contact (DC) Max Rating R Load .02A@20VDC
Operating Force-Max 3.92 N
Dimensions
Length 8.1mm
Body Height 8.64mm
Actuator Length 0m
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
