RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Pushbutton Switches 4PDT PSH-ON PSH-OFF
PDF
/
Buying Options
Total Price: USD $63.5
Unit Price: USD $63.499721
≥1 USD $63.499721
≥200 USD $25.337657
≥500 USD $24.490837
≥1000 USD $24.072022
Inventory: 1197
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Actuator Length 0.48 inch
Length - Termination 0.16 inch
Body Height 19.81mm
Technical
Actuator Finish NICKEL
Bushing Diameter 0.25 inch
Washability SOLVENT
Operating Force-Max 12.01 N
Bushing Length 0.28 inch
Solderability HAND
Actuator Travel 3.556 mm
Contact Function ON-OFF
Contact Voltage(AC)-Max 125V
Contact Timing BREAK-BEFORE-MAKE
Contact Current(AC)-Max 6A
Electrical Life 50,000 Cycles
Dielectric Withstanding Voltage 1500VRMS V
Contact Voltage(DC)-Max 28V
Sealing IP65
Contact Current(DC)-Max 4A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-On
Circuit 4PDT
Actuator Type Plunger for Cap
Body Breadth 13 mm
Body Length or Diameter 22.58mm
Voltage - Rated AC 125V
Termination Style Solder Lug
Ingress Protection Splash Proof
Current Rating (Amps) 6A AC 4A DC
Voltage - Rated DC 28V
HTS Code 8536.50.90.33
Type Standard
ECCN Code EAR99
Part Status Active
Series MPE
Published 2012
Packaging Bulk
Operating Temperature -20°C~80°C
Physical
End Contact Plating GOLD
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Center Contact Plating GOLD OVER SILVER
Actuator Material BRASS
Insulation Material THERMOSET 94V-0
Mounting Feature PANEL MOUNT-THREADED
Surface Mount NO
Mounting Type Panel Mount, Rear
Supply Chain
Factory Lead Time 25 Weeks
