RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSHBUTTON DPDT 6A 125V
PDF
/
Buying Options
Total Price: USD $18.46
Unit Price: USD $18.4624
≥1 USD $18.4624
≥10 USD $16.011776
≥100 USD $14.598848
Inventory: 55
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Dimensions
Actuator Length 13.97mm
Body Height 11.68mm
Width 13mm
Length 13mm
Technical
Actuator Finish NICKEL
Bushing Diameter 0.25 inch
Washability SOLVENT
Operating Force-Max 19.61 N
Solderability HAND
Actuator Travel 3.556 mm
Contact Voltage(AC)-Max 125V
Contact Current(AC)-Max 6A
Contact Current Rating 6A
Electrical Life 50,000 Cycles
Dielectric Withstanding Voltage 1500VRMS V
Contact Voltage(DC)-Max 28V
ELV Compliant
Sealing MOLDED
Contact Current(DC)-Max 4A
Insulation Resistance 1000000000Ohm
Contact Resistance 0.01mOhm
Panel Cutout Dimensions Circular - 6.35mm Dia
Switch Function On-Mom
Circuit DPDT
Actuator Type Plunger for Cap
Voltage - Rated AC 125V
Termination Style Solder Lug
Orientation Vertical
Current Rating (Amps) 6A AC 4A DC
Voltage - Rated DC 28V
HTS Code 8536.50.90.31
Type Standard
ECCN Code EAR99
Termination Lug
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MPA
Published 2004
Packaging Bulk
Operating Temperature -20°C~80°C
Physical
Insulation Material THERMOSET 94V-0
Mounting Type Panel Mount, Rear
Mount Panel
Contact Plating Gold
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 19 Weeks
