1977737-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSH SPDT 0.06A 30V
PDF
/
Buying Options
Total Price: USD $45.52
Unit Price: USD $45.519556
≥1 USD $45.519556
≥200 USD $18.162659
≥500 USD $17.556099
≥1000 USD $17.256758
Inventory: 973
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 21 Weeks
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Physical
Contact Material Brass
Contact Plating Gold
Mount Panel, Screw
Mounting Type Panel Mount, Rear
Actuator Material Nickel
Technical
Operating Temperature -20°C~80°C
Packaging Bulk
Published 2011
Series Blue
Feature Tactile/Audible Feedback
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Lug, Solder
ECCN Code EAR99
Type Standard
Voltage - Rated DC 30V
Current Rating (Amps) 60mA DC
Current Rating 60mA
Termination Style Solder Lug
Actuator Type Plunger for Cap
Circuit SPDT
Switch Function On-On
ELV Compliant
Electrical Life 50,000 Cycles
Max Voltage Rating (DC) 30V
Mechanical Life 50000 cycles
Contact Current Rating 60mA
Dimensions
Actuator Length 8.001mm
Compliance
RoHS Status RoHS Compliant
