Inventory: 4965
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
Lead Free Not Applicable
RoHS Status RoHS Compliant
REACH SVHC Unknown
Dimensions
Actuator Length 3.05mm
Technical
Contact Voltage Rating (DC) 24V
Contact Voltage Rating (AC) 250V
Actuator Diameter 14.986 mm
Contact Rating (Current) 5A
Illumination Color Green
Illumination Type Illuminated, Lamp
Mechanical Life 100000 cycles
Max Voltage Rating (DC) 24V
Throw Configuration DPST
Number of Poles 1
Electrical Life 100000 cycles
Max Voltage Rating (AC) 250V
ELV Compliant
Contact Resistance 20mOhm
Approval Agency CE, UL
Voltage - Rated AC 250V
Current Rating 5A
Orientation Straight
Voltage - Rated DC 24V
Power Rating 400mW
Voltage - Rated 250V
Min Operating Temperature -20°C
Max Operating Temperature 50°C
Number of Positions 2
Type Switch
Termination Solder
Physical
Mount Panel
Contact Plating Gold
Contact Material Silver
