BXR023
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SQUARE PUSHBUTTON SWITCHES FRONT MOUNT, .620 MOUNTING HOLE
PDF
/
Inventory: 4586
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Actuator Length 2.77mm
Body Height 22.8mm
Length 17.65mm
Technical
Body Color GRAY
Contact Function ON-(ON)
Contact Voltage(AC)-Max 120V
Contact (AC) Max Rating R Load .25A@120VAC
Contact Current(AC)-Max 0.25A
Contact Current Rating 250mA
Max Current Rating 250mA
Sealing DUST PROOF
Color - Actuator/Cap Black
Panel Cutout Dimensions Square - 15.75mm2
Switch Function On-Mom
Circuit SPDT
Actuator Type Square, Button
Body Breadth 15.5 mm
Voltage - Rated AC 115V
Termination Style Quick Connect - 0.110 (2.8mm)
Current Rating 250mA
Depth 17.65mm
Orientation Straight
Current Rating (Amps) 250mA AC
HTS Code 8536.50.70.00
Additional Feature ADJUSTO-CLIPS
Type Standard
ECCN Code EAR99
Termination Quick Connect
Part Status Active
JESD-609 Code e4
Series BXR
Published 2001
Packaging Bulk
Physical
End Contact Material COPPER ALLOY
Terminal Material COPPER ALLOY
Actuator Material Plastic
Mounting Type Panel Mount, Snap-In
Mount Panel, Snap in
Contact Plating Silver
Supply Chain
Factory Lead Time 12 Weeks
