1241.6933.1122000
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Pushbutton Switches
Description
SWITCH PUSHBUTTON DPDT 5A 125V
PDF
/
Buying Options
Total Price: USD $29.24
Unit Price: USD $29.2424
≥1 USD $29.2424
Inventory: 106
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Body Height 39.15mm
Technical
Contact Voltage Rating (DC) 125V
Contact Voltage Rating (AC) 250V
Outside Diameter 25 mm
Contact Current(AC)-Max 5A
Forward Voltage 2V
Illumination Type LED
Operating Force 5 N
Forward Current 20mA
Mechanical Life 1,500,000 Cycles
Number of Poles 2
Electrical Life 200,000 Cycles
Illumination Type, Color LED, Green
Illumination Voltage (Nominal) 2.1VDC
Color - Actuator/Cap Silver
Insulation Resistance 100MOhm
Contact Resistance 30mOhm
Panel Cutout Dimensions Circular - 22.10mm Dia
Switch Function On-Mom
Circuit DPDT
Actuator Type Round, Button, Flush
Voltage - Rated AC 125V
Termination Style Quick Connect - 0.110 (2.8mm)
Current Rating 5A
Ingress Protection IP40
Packing Method BOX
Current Rating (Amps) 5A AC
HTS Code 8536.50.70.00
Voltage - Rated 250V
Color Green
Type Anti-Vandal, Illuminated
ECCN Code EAR99
Termination Quick Connect
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Pbfree Code yes
Series MSM DP
Packaging Bulk
Operating Temperature -25°C~85°C
Physical
Material Stainless Steel
Package / Case 125
Mounting Type Panel Mount, Front
Mount Front, Panel
Supply Chain
Factory Lead Time 14 Weeks
