1241.2801
RoHS
RoHS compliant
RoHS compliantPackage 125
Category Switches / Pushbutton Switches
Description
SCHURTER 1241.2801 Vandal Resistant Switch, MCS19 Series, SPST-NO, Natural, Solder, 125 mA
PDF
/
Buying Options
Total Price: USD $8.76
Unit Price: USD $8.76408
≥1 USD $8.76408
≥10 USD $8.268
≥100 USD $7.8
≥500 USD $7.35849
≥1000 USD $6.94197
≥3000 USD $6.54903
Inventory: 1970
Minimum: 1
-
+
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Body Height 8.8mm
Width 21.5mm
Length 22mm
Technical
Actuator Finish NICKEL
Actuator Travel 0.4064 mm
Contact (AC) Max Rating R Load A@VAC
Operating Force 3.7 N
Contact Current Rating 125mA
Mechanical Life 1,000,000 Cycles
Max Voltage Rating (DC) 48V
Throw Configuration SPDT, SPST
Electrical Life 1,000,000 Cycles
Max Current Rating 125mA
Sealing IK05; IP40; IP65
Insulation Resistance 100MOhm
Contact Resistance 0.05mOhm
Panel Cutout Dimensions Circular - 19.00mm Dia
Switch Function Off-Mom
Circuit SPST-NO
Actuator Type Round, Button, Flush
Termination Style Solder Lug
Current Rating 125mA
Depth 22mm
Ingress Protection IP65 - Dust Tight, Water Resistant
Packing Method BOX
Current Rating (Amps) 125mA DC
Voltage - Rated DC 48V
HTS Code 8536.50.90.31
Additional Feature VANDAL PROOF
Terminal Finish Tin (Sn)
Number of Positions 2
Type Anti-Vandal
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) Vendor Undefined
Part Status Active
Feature Tactile Feedback
JESD-609 Code e3
Series MCS
Packaging Bulk
Operating Temperature -20°C~60°C
Physical
End Contact Material BRASS
Center Contact Material BRASS
Actuator Material ZINC DIE CAST
Weight 10.199988g
Housing Material ZINC DIE CAST
Package / Case 125
Mounting Type Panel Mount, Front
Mount Front, Panel
Contact Plating Silver
Supply Chain
Factory Lead Time 15 Weeks
