A3SA-90A1-24SO
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SWITCH PUSHBUTTON SPDT 3A 125V
PDF
/
Buying Options
Total Price: USD $41.63
Unit Price: USD $41.6328
≥1 USD $41.6328
Inventory: 16
Minimum: 1
-
+
Technical Details
Physical
Mount Panel, Snap in
Mounting Type Panel Mount, Snap-In
Technical
Operating Temperature -10°C~50°C
Packaging Bulk
Published 2013
Series A3S
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Quick Connect
ECCN Code EAR99
Type Standard, Illuminated
Voltage - Rated DC 30V
Current Rating (Amps) 3A AC 2A DC
Ingress Protection IP00
Reach Compliance Code unknown
Current Rating 2A
Termination Style Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 125V
Actuator Type Square, Button
Circuit SPDT
Switch Function On-Mom
Panel Cutout Dimensions Square - 16.20mm2
Color - Actuator/Cap Orange
Illumination Voltage (Nominal) 24VAC/DC
Illumination Type, Color LED, Orange
Electrical Life 100,000 Cycles
Mechanical Life 1,000,000 Cycles
Illumination Type LED
Compliance
RoHS Status RoHS Compliant
