A22L-TY-6D-01M
RoHS
/
Package /
Category Switches / Pushbutton Switches
Description
Illuminated Pushbutton Switches SPST-NC MO RN 6VD YL IP65 LED ext act
PDF
/
Inventory: 2282
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP65, Water Resistant
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Body Height 54.7mm
Technical
Illumination Type LED
Contact Current Rating 10mA
Mechanical Life 5,000,000 Cycles
Throw Configuration SPST
Electrical Life 500,000 Cycles
Contact Voltage(DC)-Max 6V
Illumination Type, Color LED, Yellow
Illumination Voltage (Nominal) 6VDC
Color - Actuator/Cap Yellow
Panel Cutout Dimensions Circular - 22.30mm Dia
Switch Function On-Mom
Circuit SPST-NC
Actuator Type Round, Button
Body Breadth 30 mm
Body Length or Diameter 36mm
Voltage - Rated AC 110V
Termination Style Screw Terminal
Current Rating 10A
Reach Compliance Code unknown
Ingress Protection IP65 - Dust Tight, Water Resistant
Current Rating (Amps) 10A AC/DC
Voltage - Rated DC 24V
HTS Code 8536.50.70.00
Type Standard, Illuminated
ECCN Code EAR99
Termination Screw
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series A22
Published 1998
Packaging Bulk
Operating Temperature -20°C~55°C
Physical
Mounting Type Panel Mount, Front
Mount Front, Panel
