YB16WCKW01-05-EB
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
SPDT ON-ON PANEL SEAL ROUND BUSH
PDF
/
Inventory: 5946
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Panel Mount, Front
Surface Mount NO
Mounting Feature PANEL MOUNT-THREADED
Technical
Operating Temperature -25°C~50°C
Packaging Bulk
Series YB
Feature Epoxy Sealed Terminals
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Type Standard, Illuminated
Voltage - Rated DC 30V
Current Rating (Amps) 3A AC/DC
Ingress Protection IP65 - Dust Tight, Water Resistant
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 125V
Body Length or Diameter 15mm
Actuator Type Round, Button
Circuit SPDT
Switch Function On-On
Panel Cutout Dimensions Circular - 16.00mm Dia
Color - Actuator/Cap Yellow (White Filter/Diffuser)
Contact Current(DC)-Max 3A
Illumination Voltage (Nominal) 5VAC
Illumination Type, Color Incandescent, Yellow
Sealing IP65; MOISTURE PROOF; PANEL SEALED
Contact Voltage(DC)-Max 30V
Electrical Life 100,000 Cycles
Mechanical Life 200,000 Cycles
Contact Current(AC)-Max 3A
Contact (AC) Max Rating R Load 3A@250VAC
Contact Voltage(AC)-Max 250V
Operating Force-Max 1.67 N
Dimensions
Body Height 17mm
Compliance
RoHS Status ROHS3 Compliant
