YB15CKW01-1F24-JF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Switches / Pushbutton Switches
Description
Pushbutton Switches SPDT RND GREEN ILLUM
PDF
/
Buying Options
Total Price: USD $5.74
Unit Price: USD $5.741312
≥1 USD $5.741312
Inventory: 6708
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Silver
Mount Front, Panel
Mounting Type Panel Mount, Front
Housing Material Polyamide
Technical
Operating Temperature -25°C~50°C
Packaging Bulk
Published 2002
Series YB
Feature Epoxy Sealed Terminals
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Type Standard, Illuminated
Voltage - Rated DC 30V
Current Rating (Amps) 3A AC/DC
Current Rating 3A
Termination Style Solder, Quick Connect - 0.110 (2.8mm)
Voltage - Rated AC 125V
Actuator Type Round, Button
Circuit SPDT
Switch Function On-Mom
Panel Cutout Dimensions Circular - 16.00mm Dia
Color - Actuator/Cap Clear (Green Filter/Diffuser)
Illumination Voltage (Nominal) 24VDC
Illumination Type, Color LED, Green
Electrical Life 100,000 Cycles
Mechanical Life 1,000,000 Cycles
Contact Current Rating 3A
Illumination Type Illuminated, LED
Illumination Color Green
Compliance
RoHS Status ROHS3 Compliant
Flammability Rating UL94 V-0
